A.   Introduction:

Motor-driven at speed 150~200rpm, revolving set circumference ready’s winder, wind certain circles and length yarn in order to obtain yarn's lea strength and after balance weighing to calculate yarn counts.

Industry: Textile

B.  Photo reference:

C.   Specification:

1.     Number of yarn skeins: 5 sets.

2.     Rotary Speed: 200 rpm.

3.     Circumference: 1m/turn or 1.5yard/turn

4.     Counter: 0~99,999 times(5 digits). Set auto stop.

5.     Power supply: Single phase, 110V or 220V

6.     Dimension: 90x50x65cm

7.     Weight: 60kg

D.   How to test:

1.     Yarn measurement: operating this tester together with balance (with decimal point, 0.01g)

    Denier, D: each 450m of material contents 0.05g which is defined as one Denier.

    Tex: Each 1000m divided by weight (g) is defined one Tex.

2.     LEA Strength：80 circles stands for 120 yards, one LEA. Use Tensile Testing Machine to test with the special grip for yarn, diameter 2.5cm; tensile speed 304.8 ± 12.7mm/min, the force on break point is Lea strength.
