A. Introduction:
This machine was made for to simulate under the actual usage of the toothbrush, it can combine with different load force of the user. To determine the cleaning ability of the toothbrush by cleaning and coloring agents which to simulate the fading condition of the sordes.
B. Photo reference:
|
 |
|
Machine |
Toothbrush models and grips |
C. Specification:
1. Load：Min. 400g. Calculated based on the whole configuration of the grips compressed onto the machine.
2. Stroke：X=4cm, Y=2cm.
3. Speed：10~ 100 times/ min (Reciprocating motion).
4. Toothbrush grips x4. (405g for each)
5. Testing cycles：0~9,999,999, automatic stop.
6. Watering device：Control independent (ex: aquarium pump).
7. Testing area made by stainless steel in order to avoid rusting.
8. Coloring agents and tooth models are not included.(User prepare; User provides the drawing with extra cost)
9. Dimension: 66x46x36cm
10. Weight: approx. 30kg
11. Analysis Software
12. Warranty: 1 year
